Factory Lead Time

16 Weeks

Mount

Panel, Through Hole

Mounting Type

Through Hole

Package / Case

Module

Number of Pins

10

Published

2007

JESD-609 Code

e3

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

ECCN Code

5A991.B.5.A

Connector Type

MTRJ

Terminal Finish

Matte Tin (Sn)

Max Operating Temperature

70°C

Min Operating Temperature

0°C

Applications

Ethernet

Additional Feature

OPTICAL OUTPUT POWER FOR THIS FIBER SIZE 62.5/125: 0.026 MW

HTS Code

8517.62.00.50

Supply Voltage

3.3V

Max Output Current

50mA

Operating Supply Voltage

3.3V

Supply Voltage-Max (Vsup)

3.465V

Output Current

50mA

Data Rate

100Mbps

Rise Time

3ns

Fall Time (Typ)

3 ns

Fiber Type

50/125, MMF

Fiber Optic Device Type

TRANSCEIVER

Built-in Feature

AMPLIFIER

Operating Wavelength-Nom

1308 nm

Emitter/Detector Type

LED, PIN PHOTODIODE

Optical Power Output-Nom

0.009mW

Communication Standard

ATM, OC-3C, SDH, SONET, STM-1

Height

9.8mm

Length

49.56mm

Width

13.59mm

Radiation Hardening

No

RoHS Status

ROHS3 Compliant

Lead Free

Lead Free
